The stand for physical modeling of reservoir conditions

The stand for physical modeling of reservoir conditions is used for simulation of uniform pressure on a sample of reservoir rock.

The cylindrical samples of rocks (30 mm in height, 30 mm in diameter) will be pressure test from 0,1 up to 100 МPа. The samples are under investigation of the pressure dependences of resistance and elastic properties.

The stand for determination of porosity and absolute permeability of the rock samples

The stand is used for determination of porosity with gas-volumetric method (a) and for absolute permeability (b) of the rock samples.

The cylindrical samples of rocks (30 mm in height, 30 mm in diameter) are being saturated with nitrogen and then the pressure difference is determined. Rock porosity determination range is 0,1 – 30%.

Pressure injection test (1 МPа) to assess the absolute permeability of rocks in the range 0,001 – 1000 fm².

Vacuum saturation unit

The unit is used for vacuum saturation of rock samples with working solution (model reservoir liquid, kerosene or reagents).

The unit provides saturation of rock samples under vacuum (to 0,1 МPа) and has the vacuum chamber (vol. 5L).

The unit for determination of air permeability of rocks and construction materials

The unit is used for determination of gas permeability of rocks, consolidated construction materials and also the full-sized samples of core from oil and gas wells.

Specification:
Tensile stress range: 0,2 – 20 kN.
Coefficient of permeability determination range: 0,001 – 1000 fm².
Operation temperature: +5 – +50 ^°С.

Megger

Megger (megaohmmeter С.А 6547) is used for determination of electric resistance of dry samples of rocks

Specification:
Electric resistance determination range: 30 kOhm – 10 TOhm.
Device is capable of recording of electric resistance changes of the samples with 5 sec frequency using laptop.

Resistance meter unit

The unit is used to determination of electric resistance of NaCl solution saturated rock samples with resistance meter С.А 6470N

Specification:
Electric resistance determination range: 0,01 Ohm – 100 kOhm.
Device is capable of recording of electric resistance changes of the samples with 5 sec frequency using laptop.

Precision RLС-meter

The unit is used for determination of electric resistance and electric capacity of rock samples (both dry and saturated with NaCl). Precision RLС-meter is capable of recording of readings using laptop.

Specification:
Frequency range: from 0 up to 100 kHz.
Electric resistance determination range: from 1·10^-5 up to 1·10¹¹ Ohm.
Electric capacity determination range: from 1·10^-17 up to 10 F.

General-purpose radiometer

Radiometer unit (DKS-96-05) is used for determination of neutron, alfa-, beta- and gamma-rays.
The unit is used to asses radioecological situation.

Specification:
Measurement range for equivalent dose of gamma-rays is from 1 μSv/h up to 1 Sv/h.
Beta-ray flux measurement range is  from 10 to 1·10⁵ β-part./(min.*cm²).
Alfa-ray flux measurement range is  from 0,1 up to 1·10⁴ α- part./(min.*cm²).
Measurement range for equivalent dose of neutron-rays is  from 0,1 μSv/hour up to 0,1 Sv/hour.
The radiometer unit is capable of recording of readings using laptop.

Low Background Radiation Detection Device

Low Background Radiation Detection Device (UMF-2000) is used for measurement of alfa- and beta- activity of powdered rock and soil samples.

Specification:
Alfa-ray activity measurement range is  from 0,1 to 3·10³ Bq.
Beta-ray flux measurement range is  from 0,01 up to 10³ Bq.
Device is capable of recording of readings using laptop.
